Description
9-Point Remote Grease Manifold Kit - M10x1 Ports - Zinc-nickel Carbon Steel - Complete with Fittings, Hose and Hardware
SKU: RGBCS-9
This Kit Contains:
- 9-Point Carbon Steel Manifold with Zerk Fittings and Protective Covers
- (1634) High Pressure Grease Fitting – Short
- 13/32" Grease Fitting Protector – Yellow
- 6 mm Tube x 1/8 NPTM Straight Fitting
- 8 mm Hose Connector (pictured hose is unfilled)
- 27 Meters (88.6 ft) of 8 mm HP Grease-Filled Hose (100-001-M) – approximately 3 meters per point
- Threaded Sleeves (100-050)
- Tubular Socket Straight (100-051) – elbows available upon request
- 1/8 NPTM x 6 mm Tube Elbow (106-104-NPT) for bearing connection
Default Configurations Terminate at the Bearing with 1/8 NPT elbow
Material Options
- Stainless Steel versions are available.
- Call (413) 788-5823 to order or customize this kit to your specifications.
Important Note
- Each grease point requires its own dedicated line.
- Do not split or tee grease tubes, as grease will always follow the path of least resistance.
Applications
- Manufacturing: food processing, paper mills, wastewater treatment, and other industrial facilities
- Agricultural Equipment: tractors, harvesters, balers, diggers, trailers, and milking machines
- Transportation: trucks, trailers, and vocational specialty vehicles
- Mining: mobile machinery such as excavators, crushers, and screeners, as well as stationary equipment like conveyors and processing plants
- Oil & Gas: drill rigs, pumps, and other lubrication-critical systems
Contact Us
For more information about Remote Grease Manifold Kits, or to determine if our lubrication equipment is the right choice for your design, contact our professionals at (413) 788-5823.
