Description
ILC Adjustable Compression Elbows
ILC Adjustable Compression Elbows connect metric tubing to threaded ports in centralized lubrication systems. Their adjustable design allows the elbow to be positioned during installation and secured in place when tightened.
Available for 4 mm, 6 mm, and 8 mm tubing with multiple male thread configurations.
Available Variations
- 4 mm Tube × M6x0.75 Male Thread (03.355.1)
- 4 mm Tube × M6x1 Male Thread (03.355.0) - Call to order
- 4 mm Tube × M8x1 Male Thread (03.351.0) - Call to order
- 4 mm Tube × G1/8 Male Thread (03.351.1) - Call to order
- 6 mm Tube × M10x1 Male Thread (03.350.0) - Call to order
- 6 mm Tube × M12x1 Male Thread (03.519.3) - Call to order
- 8 mm Tube × M12x1 Male Thread (03.519.4) - Call to order
Special Order Information
Fittings marked Call to Order are not part of our regular stock and are available by special order with a minimum order quantity of 50 pieces per fitting. Lead times may vary.
Please contact us online or call (413) 788-5823 for availability and ordering information.
