ILC TWIN Electric Dual Line Lubrication Pump - 100 kg
High-pressure grease delivery for large and demanding Dual Line lubrication systems.
SKU: 58.G.10.SU.1.1.B.1.X
The ILC TWIN Electric Dual Line Lubrication Pump is designed to supply centralized Dual Line lubrication systems on medium and large machinery operating in demanding industrial environments. Dual Line systems are well suited for complex installations with large numbers of lubrication points and distribution lines that can extend beyond 100 meters (328 ft).
This configuration features a 100 kg grease reservoir, 230/480V AC three-phase motor, 24V DC reversing valve, laser minimum/maximum level sensor, and reservoir heating band. The TWIN pump uses two alternately driven pumping elements to provide continuous, uniform lubricant delivery for high-pressure Dual Line systems.
Features & Benefits
- Designed specifically for Dual Line lubrication systems
- 100 kg grease reservoir
- 230/480V AC three-phase motor
- High-pressure operation for large and complex lubrication systems
- Dual pumping elements provide consistent lubricant delivery
- 24V DC reversing valve included
- Laser minimum/maximum level monitoring
- Reservoir heating band
- UL-CSA configuration
- Heavy-duty construction for demanding industrial environments
- Suitable for Dual Line systems extending beyond 100 m (328 ft)
- Pallet-mounted configuration
Applications
- Mining equipment and facilities
- Steel mills
- Cement plants
- Drilling platforms
- Large cranes and material-handling equipment
- Large industrial machinery and production equipment
Additional Information
For more information about this product or assistance selecting the right lubrication equipment for your application, contact us online or call (413) 788-5823.
